Terminal Type

Cell Layout (Polarity)

Base Hold Down

Frequently Asked Questions

How do I read a DIN model number such as DIN60-56068?

In DIN naming, the number after DIN is the nominal capacity in ampere-hours, so DIN60 means 60Ah. The five-digit code that follows identifies the exact case size, polarity and terminal arrangement defined by the DIN standard, which makes cross-referencing against OEM part numbers straightforward for European vehicles.

What is the difference between L and LB size groups in the DIN range?

LB groups (LB1 to LB5) are the low-height versions at 175mm, while L groups (L1 to L5) share the same footprint but are 190mm tall. Both fit the same tray width, so the choice depends on the clearance available under the hood or hold-down frame of the vehicle.

Which vehicles are the large DIN models designed for?

The D4, D6 and D8 size groups from 120Ah to 225Ah are built for heavy-duty applications such as trucks, buses and off-highway equipment, delivering CCA from 860A up to 1300A for reliable cold starting in commercial fleets.

What does Ah(@20HR) in the capacity column mean?

Ah(@20HR) is the nominal capacity, the charge a battery can deliver over a 20-hour discharge at the specified rate. For example, a DIN44 battery supplies 44Ah under this test, which is why the capacity figure appears in the model name of most DIN types.

What do the Base Hold Down codes B0 and B13 mean?

These codes describe the mounting feet cast into the battery base. B0 stands for a flat bottom without hold-down ledges, while B13 identifies the standard ledged foot engaged by most European tray clamps. Matching the code ensures the original hold-down hardware fits without modification.

Terminal Type

Cell Layout for BCI Standard

Base Hold Down

Frequently Asked Questions

What does BCI group size mean on the model list?

BCI (Battery Council International) group numbers such as BCI 24, BCI 35 and BCI 65 define the case length, width, height and terminal type of the battery. Any battery built to the same BCI group size fits the same vehicles, which makes the group number the quickest cross-reference for American and Korean applications.

What is RC (Reserve Capacity) in the BCI specification?

Reserve Capacity is the number of minutes a fully charged battery can deliver 25 amps at 27°C before its voltage falls below 10.5V. In this range RC runs from 63 minutes on the compact BCI 51 models up to 191 minutes on BCI 31, showing how long essential loads can keep running if the charging system fails.

What does CCA A(SAE) mean in the BCI table?

CCA measured to the SAE standard is the current a battery delivers for 30 seconds at -18°C while maintaining at least 7.2V. In this range CCA values run from 420A to 1300A. Besides the standard A top terminal, the BCI range also offers TOP, STUD and SIDE terminal variants for commercial and special applications.

What does the number after the dash in BCI model names mean?

In names such as 48-560 or 49-850, the first part is the BCI group number and the second is the CCA rating of that specific model. This makes it easy to compare starting power within the same group: same case size, different performance levels to match your climate and budget.

How do I choose the correct BCI group for my vehicle?

The group number defines the case footprint, terminal position and hold-down type. Measure your old battery or tray and compare it with the Length, Width and Height columns in this table, then confirm the terminal type matches your cable routing. The WESTERN SMF ENDURANCE range covers the most popular groups.
